3.2V 25Ah Lifepo4 Rechargeable Battery , Lithium Iron Phosphate Battery Pack ≤4mΩ

Product Categories

Shenzhen Topband Battery Co., Ltd

Contact Now

3.2V 25Ah Lifepo4 Rechargeable Battery , Lithium Iron Phosphate Battery Pack ≤4mΩ

Name: 32V 25Ah Lifepo4 Rechargeable Battery Lithium Iron Phosphate Battery Pack 4mΩ
Brand: Topband
Price: 1 USD

Buy cheap 3.2V 25Ah Lifepo4 Rechargeable Battery , Lithium Iron Phosphate Battery Pack ≤4mΩ product

Brand Name : Topband

Model Number : TB-027070180C-Fe-25Ah

Certification : CE, TUV, UL, UN38.3, etc.

Place of Origin : China

MOQ : 100

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 1GWH/year

Delivery Time : 10-30 days

Packaging Details : Standard Export Package

Nominal Voltage : 3.2

Nominal Capacity : 25Ah

Charge voltage : 3.65V

Charge current : 1C(25A)

Discharge current : 3C(75A)

Peak discharge current(3s) : 5C(125A)

Weight : 610±20g

Dimension : 27*70*180mm

Impedance : ≤4mΩ

cycle life : ≥2500(1C/1C)

Contact Now

3.2v 25Ah Lifepo4 Rechargeable Battery , Lithium Iron Phosphate Battery Pack ≤4mΩ

Specifications:

NO	Items		Characteristics
2.1	Normal capacity		25Ah
	Minimum capacity		24.5Ah
2.2	Nominal energy		80Wh
2.3	Nominal voltage		3.2V
2.4	Internal resistance		≤4mΩ @1kHz AC
2.5	Normal charge voltage		3.6±0.5V
2.6	Float charge voltage(for Standby use)		3.4±0.8V
2.7	Allowed MAX charge current		25A
2.8	Recommended charge current		5A
2.9	Allowed MAX discharge current		75A
2.10	End of discharge voltage		3.1V~3.4V
2.11	Pulse discharge current		Withstand the 125A/10s
2.12	Dimension		Length 180 ±1 mm
			Width 70±1mm
			Height 27±1 mm
2.13	Weight (No accessories)		About: 610±20g
2.14	Operation temperature	Charge	0～43℃
		Discharge	-20～60℃
2.15	Self-discharge rate		≤3%/Month; ≤15%/ year
2.16	Storage environment	≤1month	-20～+60℃,5～75%RH
		≥3month	-10～+43℃,5～75%RH
		Recommend environment	15～33℃,5～75%RH

LFP cell 3.2V series:

Model	TB-027070145E-Fe-20Ah	TB-027070180D-Fe-25Ah	TB-A32173128P-Fe-50Ah	TB-48174170-Fe-100Ah
Nominal voltage	3.2V	3.2V	3.2V	3.2V
Nominal capacity	20Ah	25Ah	50Ah	100Ah
Cycle life	≥2500	≥2500	≥2000	≥2000
Weight	520±20g	660±20g	1350±50g	2600±50g
Dimension	2770145mm	2770180mm	32173128mm	48174170mm

Advantages:

1. F series battery use LiFePO4 cells, with super safe chemistry property
2. Battery with built-in self-development high-performance BMS
3. With built-in Bluetooth IC, patent design
4. High in-rush current capability, protect battery and inverters compatible
5. Wide temperature range design, workable at -30~50 , 70% discharge at -20
6. Support max. 4pcs in series andparallel connection
7. Mature solution, stable performance
8. CE, UL, UN38.3 certificated

Main Applications:

1. Energy Storage:Solar-Wind Power System / City Grid (On/Off) / Community and Family / RV Motorhome /Golf Carts Battery / Boat Marine Yachts / Electric Skateboard / Vehecle.
2. Back-up System and UPS:Telcom Base / CATV system / Computer Server Center / Medical Instrumnt / Military Equipment.
3. Other Applications:Security and Electronics / Mobile POS, Mining Lihgt / Torch / LED Light / Emergency Light / LED Backup / Engine Starting Battery,etc.

3.2V 25Ah Lifepo4 Rechargeable Battery , Lithium Iron Phosphate Battery Pack ≤4mΩ

Packaging & Shipping

1. Pack in safety industrial package, with IATA shipping standard.
2. For sample or small order: ship by DHL, UPS, FedEx and TNT etc…
3. For large order, ship by AIR or OCEAN.
